| Configuration | Pure copper |
| Load power | 420-1400W15% |
| Working voltage | 220VAC |
| Load current | 5.4A15% |
| Rated frequency | 50Hz |
| Load speed | 14000rpm15% |
| Insulatio level | Class B |
| Pressure | 1800V·1S·1mA |
| No-load power | 420W15% |
| Motor steering | CCW |
| No-load current | 1.90A15% |
| Thermostat | KW250V 5a 125℃ |
| No-load speed | 27500rpm15% |
| Lead | CCC 0.5mm² 105°C L=280mm black, 6.3*8 with locking terminal |
Product Details Page
1.The motor is suitable for 2L, 3L, 4L, 5L wall breakers
2.The motor shaft can be customized according to the customer's requirements
3.The motor can be designed with parameters according to customer requirements
4.The motor 220V/110V
